EVENT: LEANE International ADAS WORKSHOP (SEPTEMBER 2021)
After two years from last workshop we were happy to have you customers at Torino private airport for this trilling event.
Backed up by AB Dynamics itself we presented ADAS capabilities on the field with interesting scenarios created for the show.
This included AEB, syncro driving with 2 driveless syncronized cars executing more complicated tests that will help the R&D to develop the next generation ADAS.We had also an aVDS static simulator used to prepare the scenarios then can be after uploaded on the ABD robots on the track.
This September it's been very hard for LEANE team as we replicated the same event at NARDO TECHNICAL CENTER owned by Porsche the week after the event in Torino. Thank you all for been there and to all LEANE technical team to have prepared such a huge event in such a short time.
Our skilled team and our commercial people are ready to discuss with you and find the correct solution for any ADAS test scenario.
Follow us on linkedin or LEANEAUTOMOTIVE or LEANE INTERNATIONAL web sites.!!!
#LEANE #LEANEAUTOMOTIVE #ADAS #AUTOMOTIVE
NEWS: DEWESOFT X 2021.5 - Dewesoft ALL new Data Acquisition Software
The all new 2021.5 Dewesoft X is out. Your best companion for data recording and data analysis wears an all new dress.
The changes are not only limited on the improved user experience, but software is been rewritten for optimization and for added functionality.
One stop solutions for electric motor and inverter testing, battery and battery charge testing, combustion analysis, NVH.
New Orbit Analysis for precise rotor movement measurements.
Historian Database allows to monitor long-term applications.
Please contact our LEANE Team for questions and all your #AUTOMOTIVE requests.
NEWS: LEANE AUTOMOTIVE DIVISION NEW CATALOGUE
We LEANE Automotive Team are very glad to present the all new and redesigned LEANE catalogue.
You'll find the complete set of solutions we can offer, how we can help you to reach your goals, either via a tailored solution or via our support team during your track days.
And if you need to perform a measurement but you don't know how ,you can even rent our instrumentation or ask us to do it for you.
Our expertise is here to serve you.
Don't hesitate to contact us.
NEWS: DEWESOFT NEXT GENERATION POWER ANALYZER WITH SIRIUS XHS
Electric and Hybrid cars are reaching the mass market with longer ranges and more reasonable pricing.To Evaluate power consumption of such vehicles tests are needed.
To measure power Consumption, measurements of voltage and current must be performed safely and with no influence of the car impedance.
The new SIRIUS XHS data acquisition system from Dewesoft is the first DAQ device with Hybrid ADC technology that makes possible to measure power during real drive tests accurately, and with no influence of the cable shield.
Advanced and easy to use solutions for complete electric and Hybrid vehicle testing in the development, validation and production phase.
One stop solutions for electric motor and inverter testing, battery and battery charge testing, combustion analysis The all new DEWEsoft SIRIUS XHS with the new Hybrid ADC Technology is capable of high-bandwidth transient recording and very high Dynamic.
Made for your very demanding application such as Vehicle Power Analysis, Combustion Analysis, E-Mobility, Power Quality Analyzer where the highest precision is an absolute necessity.
The power analysis module allows measuring every kind of motor (1-12 phase) and inverter (DC-AC, AC-AC, switching frequencies up to some 100kHz).
Modular DAQ system allows measuring the power (AC or DC) at multiple points perfectly synchronized.
Please contact our LEANE Team for questions and all your #AUTOMOTIVE requests.
SUCCESS STORY: AB DYNAMICS and LEANE INTERNATIONAL SECURE EUROPEAN COMMISSION CONTRACT :
JRC Chooses ABD as supplier of equipment for motor vehicle safety compliance and experimental testing.
LEANE Automotive as supplier of AB Dynamics equipment nails down a 4 years contract with JRC that may cover the supply of driving robots, ADAS targets , and soft impactable dummies with a contract value in excess of 2millions Euro.
JRC will use the equipment for testing autonomous vehicles and to assist with the development of future UN ECE Regulations.
LEANE International Automotive Sales Director , Cesare Bardelli , said " it's been hard work, we spent weeks to fulfil documentation and procedures, but at the end we are very proud JRC has chosen us.
We are the reps for very important companies in the automotive testing industry and AB Dynamics is one of them. Our supplied equipment is used by major italian vehicle manufacturers , and this contract is the result of decades spent in the field , helping our customers to achieve their goals."
NEWS: DEWESOFT X 2021.5 - Dewesoft ALL new Data Acquisition Software
The all new 2021.5 Dewesoft X is out. Your best companion for data recording and data analysis wears an all new dress.
The changes are not only limited on the improved user experience, but software is been rewritten for optimization and for added functionality.
One stop solutions for electric motor and inverter testing, battery and battery charge testing, combustion analysis, NVH.
New Orbit Analysis for precise rotor movement measurements.
Historian Database allows to monitor long-term applications.
Please contact our LEANE Team for questions and all your #AUTOMOTIVE requests.
VIDEO: dQDT - MEASURE OF FLUID LEAKAGE
dQdt provides high accuracy flow meters (sensor or complete solutions) for measuring fluid consumption.
Watch the video of the test bench for fluid leakage.
Key features are: 1 value per second, measuring to atmosphere, hydraulic oils and fluids, high accuracy and dynamics, traceable calibration
NEWS: AB DYnamics Swarm testing in simulation and on the track
This video demonstrates the unique capabilities that AB Dynamics can offer. We can recreate complex real-world scenarios featuring multiple moving actors with centimetre precision on the test track, and deliver the identical tests within simulation. This allows vehicles to be tested in conditions that represent real traffic events, and enables validation of simulation results.
We've used a number of edge-case traffic scenarios, with all of the vehicles shown in the video being controlled using our driving robots, plus the addition of our GST and LaunchPad ADAS platforms.
ADAS and AV developers will recognise the vital safety benefit of exposing their vehicles to these scenarios in controlled conditions before they are encountered on the public roads.
NEWS: DEWESOFT SIRIUS R2DB THE PERFECT SOLUTION FOR VEHICLE DYNAMICS and HANDLing
DEWEsoft gives you a complete solution from hardware to software for your Vehicle Dynamics testing. The solution offers a set of automated test maneuvers for vehicle dynamics and real time validation via VTS plugin. A quick pass/fail evaluation on the routine helps the driver to quickly and efficiently acquire data.
Highlights:
- Real-time results : VTS Plugin (Vehicle Test Suite) and Dewesoft X software show all validation and visualize results in real time.
- Automated Workflow: VTS plugin offers pre-defined testing maneuvers for the test operator and easy on screen controls for the operator to configure and run the tests.
- Automated results and Statistics: VTS can show a summary table with statistics and can overlay results from a batch of test runs.
- VTS Standard maneuvers set: VTS offers several standard maneuvers like Steady State Cornering, Step Speer Input , On Center Sinus Steer, Pseudo Random Steer , Sine with Dwell and so on.
- Custom VTS maneuvers set: Our LEANE team of developers can implement custom maneuvers set up to your specs.
NEWS: AB DYnamics announces new steering robot modEl HALO
AB Dynamics all new Halo joins the family of the Torus model with hollow-center installation that allows testers and engineers to leave the airbag in place.
For all your italian application, ADAS and vehicle testing and dynamics don't esitate to contact our LEANE AUTOMOTIVE team.
Halo Specifications include:
| Peak Torque | 90Nm |
| Peak rotational speed (at up to 20 Nm) | 2500'/s |
| Moment of inertia | 0.1156kg m^2 |
| Motor height | 78mm |
NEWS: Alfa ROMEO RACING AnD AB Dynamics
Driving simulators are becoming more and more necessary during testing and developing on new car strategies and configurations.
F1 Teams are forced by F1 regulations to test cars only for limited time.
Integration of realistic indoor simulators like our AB Dynamics aVDS is been choosen by Alfa Romeo F1 team as their precious help during R&D of new components, and new tracks simulations.
Watch aVDS on action.
NEWS: DEWESOFT E-MOBILITY - EDRIVE and electric vehicle testing
Advanced and easy to use solutions for complete electric and Hybryd vehicle testing in the development, validation and production phase.
One stop solutions for electric motor and inverter testing, battery and battery charge testing, combustion analysis The all new DEWEsoft SIRIUS XHS with the new Hybrid ADC Technology is capable of high-bandwidth transient recording and very high Dynamic.
Made for your very demanding application such as Vehicle Power Analysis, Combustion Analysis, E-Mobility, Power Quality Analyzer where the highest precision is an absolute necessity.
The power analysis module allows measuring every kind of motor (1-12 phase) and inverter (DC-AC, AC-AC, switching frequencies up to some 100kHz).
Modular DAQ system allows measuring the power (AC or DC) at multiple points perfectly synchronized.
Please contact our LEANE Team for questions and all your #AUTOMOTIVE requests.
NEWS: DEWEsoft COMPLETE COMBUSTION ANALYSIS SOLUTION
DEWEsoft gives you a complete solution from hardware to software for your R&D needs such as Internal Combustion Analysis, Engine Optimization, Testing of Ignition Systems, Development of Performance Exhaust Systems and more.
Highlights:
- Flexible Analog Inputs with sensor supply for any sensor and signal type: Charge, IEPE/ICP, Voltage,Strain,Torque,Temperature etc
- Direct RPM Sensor Connection, such us 60-2, Encoder,CDM+Trg, CANbus etc.
- High Speed 1Ms/s x channel sampling rate , ideal for combustion analysis on high speed engines.
- High Dynamic: Sirius amplifiers with dual 24-bit ADC x channel
- Lookup Table Generation. DEWEsoft X3 or the newest 2020 version software is capable to generate a table with all the ignition time of main and secondary injections. This is great for reverse engineering of a blocked or third party ECU.
- Portable test system : that means test wherever you want even in a track driving a car or a motorbike.
- TEST-BED and INCA Integration:The system can send combustion results to testbed via AK-protocol or to ETAS INCA via CAN.
- Lifetime free software upgrades and no annual fees. Intuitive software
NEWS: DEWESOFT HIGH SPEED DATA ACQUISITION SYSTEM : SIRIUS XHS 15Ms/s
The all new DEWEsoft SIRIUS XHS with the new Hybrid ADC Technology is capable of high-bandwidth transient recording and very high Dynamic.
Made for your very demanding application such as Vehicle Power Analysis, Combustion Analysis, E-Mobility, Power Quality Analyzer where the highest precision is an absolute necessity.
As usual DEWEsoft offers the free and all new DEWESOFT 2020 software with lifetime upgrades included in the package.
No hidden costs!!!!
Connection to the PC with GLAN and/or USB 3.0 connections and support for all the industry standard protocols like OPC UA, XCP, CAN and CAN FD.
Many DEWESOFT 2020 software plugins available for all kind of specific applications.
Please contact our LEANE Team for questions and all your #AUTOMOTIVE requests.
SUCCESS STORY: AB DYNAMICS and VW GROUP with LEANE AUTOMOTIVE TEAM HELP TO PERFORM ADAS Scenarios in ITALIAN NTC Proving ground
Automotive test systems supplier AB Dynamics has collaborated with VW, Audi and Porsche to demonstrate swarm vehicle test and a total of 152 ADAS tests carried in 11 days with the support of LEANE AUTOMOTIVE Italian AB Supplier and Vehicle test outsourcer in Nardò Technical Center (Lecce) proving ground.
Highlights:
- 11 days of testing
- 152 tests performed.
- Complex real world ADAS testing scenarios with multiple vehicles with driveless systems.
- Portable test system that means test wherever you want.
- Perfect car to car data and position sync via AB Synchro control system
- Test Scenarios simulated on your desk and then carried out on the track with a copy/paste configuration file.
NEWS: AB DYnamics new STATIC & DYNAMIC DRIVING SIMULATOR
Our high quality driving simulators (static and Dynamic) enable meaningful testing to be undertaken early in the vehicle development process.
The consistent Simpia toolchain allows for the transition from virtual testing to track testing to occur seamlessly whilst precisely correlating resuts.
AB Dynamics is one of the few companies with the technology that enables customers to progress from virtual laboratory based evaluation to real world track testing in a single digital environment.
NEWS: AB DYNAMICS NEW LAUNCHPAD 60km/h
The AB Dynamics LaunchPad is a compact powered platform designed to carry Vulnerable Road User (VRU) targets for ADAS development and testing.
Features:
- Compatible with a range of official Euro NCAP VRU targets
- Self-propelled path-following platform for total test flexibility
- 4-wheel-drive 4-wheel-steer for ultimate manoeuvrability
- Onboard D-GPS motion pack
- Rapid Battery Swap system via side ramps
- Ultra low-profile (65mm) and shallow sloping sides
NEWS: ZALAZONE Proving GROUND ADOPTS AB DYNAMICS
A new success story for AB Dynamics as ZALAZONE a state-of-the-art test facility located in Zalaegerszeg Hungary has selected their equipment and driving robots as exclusive supplier for automotive testing in their proving ground.
AB Dynamics is one of the few companies with the technology that enables customers to progress from virtual laboratory based evaluation to real world track testing in a single digital environment.
The Test facility selected SR60 Orbit steering robots with CBAR combined brake and accelerator robot so that vehicles can be controlled to drive accurately and repeatedly to create desired scenarios. ADAS targets that include guided Soft Target (GST), Soft Pedestrian Target (SPT) and LaunchPad platforms were also included in the purchase. To complete the package the FLEX-O-DRIVE-BY-WYRE control system was selected as a cost and time effective solution to control cars to be used as background traffic with complete GPS sync with all other driveless cars in the more complex ADAS scenario.
WELL DONE!!!!!!!
ADAS IN THE DARK TESTING
MoshonData is launching a new unique 300ft (91m) long tunnel for testing ADAS sensors in the dark. Exclusively available from MoshonData , the night vision tunnel provides interior light blocking to assist with the development of night vision assist technology.
The tunnel comes in six 50' long connecting sections, five emergency exits lights every 50' and three 5000 CFM exhaust fans to clear the air after every run through.
NEW PRODUCTS: MOSHON DATA MD-HANi
MOSHON DATA releases the first AEB validation tool designed for end-of-line vehicle production facilities.
This bundle include also a complete ISO standard foam vehicle target (MD-VT-F), data logger with INS and differential RTK that gives 2cm position accuracy. Relative distance , longitudinal range and lateral deviation are also recorded. A smart small display with all parameter is also included and can be installed on the windshield with a suction cup.
Data logging of all vehicle intertial and sensor data at 200Hz to SD Card.
NEW PRODUCTS: MOSHON DATA NEW KIDS ON THE BLOCK (PT)
MOSHON DATA just released an all new set of pedestrian targets for ADAS testing.
The Standard Euro NCAP pedestrian target fulfill all new requirement for all you test needs.
This include PT dimensions for both Adult and Child, low reflective skin surface, clothing and hair , and even skin color.
For more details download the full brochure clicking the link below.
APPLICATION: IN SELLA MOTORBIKE TESTING WITH THE ALL NEW SUCHY DUAL ANTENNA/DUAL GLONASS XPROGPS MAX 100 HZ
The installation and testing of the new Dual Antenna/Dual GPS SUCHY DATA SYSTEMS xProMAX GPS @ 100Hz with the custom software made by LEANE INTERNATIONAL at the AF CORSE TEST CENTER (PC) for the motorcycles magazine IN SELLA
APPLICATION: MEASURING CAR TEMPERATURE UNDER THE BONNET
As space under the car hood is always limited , engineers are always facing new challenges to get the job done, and respect the schedule of the car R&D.
Hundreds of sensors are involved during testing and reducing the time of installation is a key feature to reduce development costs.
Small form factor of the acquisition systems and neat installation it's a must.
Follow the link below to read the full article of this amazing Dewesoft Krypton application.
NEW PRODUCT: OPTIMEAS CANBus DATALOGGER
The smartMINI is a compact datalogger with 2 CANbus input that records data on a SD Card.
It can be highly customised with GPS, Input/Output Analog and Digital Channels, it is the perfect device for fleet management and can be ordered in rugged version for harsh and very demanding environment like the Rail market , Avionics.
Data can be sent over the Cloud and be collected easily sitting on your desk.
NEWS: dQDT - UREA MEASUREMENT WITH DQ-UREA-I
dQdt provides high accuracy flow meters (sensor or complete solutions) for measuring fluid consumption.
The DQDT Urea Measurement unit is perfect for test bench or on the road real measurement.
With the always more restricting emission levels , testing the correct injection of AdBlue is becoming more and more important.
NEWS: RoLL-OUT AVDS AB DYNAMICS 5-6 March at KEMPTEN UNIVERSITY
More than 100 invited guests , politicians ,business men and scientists gathered in the laboratory halls of the Adrive Living Lab of Kempten University for the roll-out of the new advanced Vehicle Driving Simulator (AB Dynamics aVDS).
Enjoy the video of the test carried out during the presentation by the official AUDI SPORT ABT Formula E Team driver, Mr. Daniel Abt.
NEW PRODUCTS: SUCHY XPROGPS_NANO 10Hz and 25Hz Version
Suchy Data Systems presents the all new GPS/GLONASS IMU aided XProGPS_nano Speed Sensor.
Integrated IMU with 6-Axis intertial sensors.
Barometric Altimeter of latest generation.
Programmable Analogue Output - directly reads speed
CANbus/USB/COM output format.
AB DYNAMICS EURO NCAP 2020 TESTING
ADAS Testing typically involves creating complex scenarios with multiple vehicles (or soft targets) to see whether the vehicle's own systems detect an imminent crash. Using AB Dynamics' robots and targets enables these test scenarios to be programmed and run quickly and accurately, giving high repeatability and consistent data.
AB Dynamics' robots and controllable soft targets have been adopted worldwide as the first choise for ADAS testing.
NEW PRODUCTS: 3D MOSHON VILLAGE
MOSHON DATA just released the complete 3D Moshon Village which has all the elements you would expect to see down your everyday street.
This is perfect for testing in an empty space such as testing track or proving ground.
Buildings, pavements, streetlights, pedestrians, vehicles, animals and even road signs to create the perfect ADAS real life scenario.
NEW PRODUCTS: DEWESOFT NEW IOLITE REALTIME DAQ
Data Acquisition and real-time control front-end system for industrial applications.
All-in-one solution for real-time control and feedback monitoring. Dual EtherCAT , great signal conditioning up to 20kHz , redundant power supply, multiple chassis option, wonderful price/performance ratio and as usual Dewesoft X3 software included with free lifetime upgrades
NEWS: GTC - GROUND TRAFFIC CONTROL AB Dynamics
Next generation software and hardware solution for monitoring, commanding and coordinating proving ground vehicle testing.
GTC is a comprehensive package for all vehicle traffic at a proving ground including : Robot-controlled vehicles, ADAS platforms, human driven vehicles and fixed proving ground infrastructure.
NEWS: Alfa ROMEO RACING AnD AB Dynamics
Alfa Romeo Racing announces AB Dynamics as official Supplier of the advanced Vehicle Driving Simulator (aVDS). Alfa Romeo Racing will use the aVDS driver-in-the-loop simulator to accelerate vehicle performance development and work with AB Dynamics to extend and further develop simulation products for motorsports applications.
MASA (MODENA AUTOMOTIVE SMART AREA) DANISI/MECCANICA 42 DEMO
Watch this amazing video where a smart car with proprietary hardware and software developed by Danisi / Meccanica 42 is able to avoid a Moshon Data MD-S target changing line .
AB DYNAMICS FLEX-0 DRIVE-BY-WIRE CONTROLLED VEHICLE
This video shows a drive-by-wire vehicle directly controlled using our Flex-0 controller. This system uses the same familiar software interface as AB Dynamics' driving robots and it is compatible with Synchro, making it suitable for use in ADAS testing.Flex-0 Controller will be shown during LEANEAUTOMOTIVE 18th September 2018 BIELLA-CERRIORE event.
AB DYNAMICS NEW TRACK-FI System
One important factor when undertaking ADAS and driverless testing is 100% reliable data transfer to the base station. For this we use our TrackFi Pro wireless telemetry system as it uses military-grade hardware and is powered by a unique meshing protocol which operates across the network giving low-latency, high-resilience communication with any other unit in the system, even with no direct connection, ensuring dependable communications coverage
VeHICLE DYNAMICS COURSES
These courses offer an opportunity to acquire from the fundamentals to the most advanced tecnique for vehicle dynamic testing and Data Analysis.
Our professional team will give you an insight in the main theoretical and practical aspects of the testing procedures and Postprocessing.
BASIC (1 Day)
INTERMEDIATE (2 Days)
ADVANCED (3 Days)
TOTAL SOLUTION COMPANY
